We’re Back

I spent a few days locked in a hellish battle against a software implementation of doubles (64-bit floats) for ARB_gpu_shader_fp64 in the raging summer heat. This scholarly infographic roughly documents my progress:


Instead of dwelling on it, I’m going to go back to something very quick and less brain-damaging, namely ARB_timer_query. This extension provides functionality for performing time queries on the gpu, both for elapsed time and just getting regular time values.

In gallium, this is represented by PIPE_CAP_QUERY_TIME_ELAPSED and PIPE_CAP_QUERY_TIMESTAMP capabilities in a driver.


Obviously there’s Vulkan extensions to go with this. VK_EXT_calibrated_timestamps is the one that’s needed, as this provides the functionality for retrieving time values directly from the gpu without going through a command buffer. There’s the usual copy-and-paste dance for this during driver init, which includes:

  • checking for the extension name
  • checking for the feature
  • enabling the feature
  • enabling the extension
  • checking for the needed extensions-specific features (in this case, VK_TIME_DOMAIN_DEVICE_EXT)

Query Time

What followed, in this case, a lot of wrangling existing query code to remove asserts and finish some stubs where timestamp queries had been partially implemented. The most important part was this function:

 static void
 timestamp_to_nanoseconds(struct zink_screen *screen, uint64_t *timestamp)
    /* The number of valid bits in a timestamp value is determined by
     * the VkQueueFamilyProperties::timestampValidBits property of the queue on which the timestamp is written.
     * - 17.5. Timestamp Queries
    *timestamp &= ((1ull << screen->timestampValidBits) - 1);;
    /* The number of nanoseconds it takes for a timestamp value to be incremented by 1
     * can be obtained from VkPhysicalDeviceLimits::timestampPeriod
     * - 17.5. Timestamp Queries
    *timestamp *= screen->props.limits.timestampPeriod;

All time values from the gpu are returned in “ticks”, which are a unit decided by the underlying driver. Applications using Zink want nanoseconds, however, so this needs to be converted.

Side Query

But then also there’s the case where a timestamp can be retrieved directly, for example:

glGetInteger64v(GL_TIMESTAMP, &time);

In Zink and other gallium drivers, this uses either a struct pipe_screen or struct pipe_context hook:

    * Query a timestamp in nanoseconds. The returned value should match
    * PIPE_QUERY_TIMESTAMP. This function returns immediately and doesn't
    * wait for rendering to complete (which cannot be achieved with queries).
   uint64_t (*get_timestamp)(struct pipe_screen *);

    * Query a timestamp in nanoseconds.  This is completely equivalent to
    * pipe_screen::get_timestamp() but takes a context handle for drivers
    * that require a context.
   uint64_t (*get_timestamp)(struct pipe_context *);

The current implementation looks like:

static uint64_t
zink_get_timestamp(struct pipe_context *pctx)
   struct zink_screen *screen = zink_screen(pctx->screen);
   uint64_t timestamp, deviation;
   VkCalibratedTimestampInfoEXT cti = {};
   cti.timeDomain = VK_TIME_DOMAIN_DEVICE_EXT;
   screen->vk_GetCalibratedTimestampsEXT(screen->dev, 1, &cti, &timestamp, &deviation);
   timestamp_to_nanoseconds(screen, &timestamp);
   return timestamp;

Using the VK_EXT_calibrated_timestamps functionality from earlier, this is very simple and straightforward, unlike software implementations of ARB_gpu_shader_fp64.

It’s a bit of a leap forward, but that’s another GL 3.3 feature done.

Written on July 15, 2020
